mcr-4v voltage data logger

TandD MCR-4V

  • 4-Channel DC Voltage Measurement
  • Coupling Units Allows for Up to 16 Channels
  • Logging Capacity: 480,000 readings
  • Shortest recording interval: 2 msec
  • Minimum Resolution of 10µV and Input Range of ±24V
  • USB or SD Memory Card for Easy Data Transfer
  • Trend Graph for Checking Data in Real Time
  • Scale and Unit Conversion
  • A 9.5% Tariff Surcharge will be added to this item at checkout

$439.00

Normal delivery 1-2 weeks

Get a QuoteGet More Info
SKU: MCR-4V Categories: , , , , , , ,

Description

MCR series loggers are 4-channel battery-operated loggers. The MCR-4V is a voltage logger which can measure up to 24V.

With multi-channels and a large internal memory (up to 480,000 readings per unit), the MCR-4V is perfect for measuring voltage and current signals at various spots for long periods of time. Moreover, by using an SD card and the “Auto Data Export” feature recording can be carried out, even when using short recording intervals, over longer extended periods of time.

MCR-4V loggers can operate on battery or USB power. Data can be checked on-site from the loggers’ LCD trend graph. Data downloaded to your PC can be viewed and analyzed with our Windows-compatible software “T&D Graph.” It is possible to connect up to four loggers, including T&D’s MCR-4TC temperature data loggers, allowing for up to 16 channels of data. This coupled with the fact that the loggers are equipped with an SD memory card slot means they are perfect for use in various experiments with large quantities of data and for tracking frequent changes in voltage and current.

The MCR-4V is convenient for measuring voltage in electrical circuits, control devices, and measurement instruments in factories, recording signals from actinometers, anemoscopes, rain sensors, and CO2 meters. The unit can record output signals from a variety of sensors and analyzers.

Specifications

Specifications

Measurement Channels Voltage 4ch
Input Method Scanning Method, Differential Input, Each Channel Isolated
Input Impedance Approx. 1.1 MΩ
Input Frequency DC – 100 Hz
Measurement Range ±300 mV, ±1.5 V, ±6 V, ±24 V, Auto (*1)
Absolute Maximum Input Voltage: ±50 V
Accuracy When the 50-60 Hz filter is ON, varies with the Measurement Range as follows:
±300 mV : ±(0.3 % + 0.06 mV)
±1.5 V : ±(0.3 % + 0.3 mV)
±6 V : ±(0.3 % + 0.6 mV)
±24 V : ±(0.3 % + 2.4 mV)
Auto : According to the range in use
Measurement Resolution 50-60 Hz Filter ON　: 0.01 mV
50-60 Hz Filter OFF : 0.1 mV
Preheat Function Allowable Voltage Range : 3 to 24 V (external power supply)
Allowable Maximum Current : 1.0 A
Recording Method Instantaneous, Average, or Ave. Fine
Recording Interval 2, 5, 10, 20, 50, 100, 200, 500 ms.
1, 2, 5, 10, 15, 20, 30 sec.
1, 2, 5, 10, 15, 20, 30, 60 min.
(The minimum interval will depend on the number of channels, measurement range, and 50-60 Hz filter setting.)
Logging Capacity (*2) When recording 1 channel : up to 480,000 readings/ch
When recording 2 channels : up to 240,000 readings/ch
When recording 3 channels : up to 160,000 readings/ch
When recording 4 channels : up to 120,000 readings/ch
Recording Mode Endless (Overwrite the most recent data when capacity is full)
One Time (Stop recording when capacity is full)
Recording Start Method Immediate Start or Programmed Start (by individual logger or by group)
Recording Stop Trigger ON or OFF
Group Recording Up to 4 units (16 channels) can be recorded simultaneously.
LCD Display Items Measurements, Trend Graph, Battery Level, etc.
Communication Interfaces USB Communication
Communication Time Download Times for Full Data via USB
– While recording (at recording interval of 2 ms.) : Approx. 3 minutes 30 seconds
– With recording stopped: Approx. 1 minute 30 seconds
– From a slave unit: Approx. 4 minutes 30 seconds
External Memory SD Memory Card, SDHC Memory Card (*3)
Power AA Alkaline Battery x 2 (AA Ni-MH batteries may also be used), USB Power (5 V 250 mA)
Battery Life (*4) Approx. 4.5 to 150 days (with AA alkaline batteries)
Input Terminal /
Preheat Terminal		 Screwless Terminals
< Compatible Wires >
Single Wire : φ 0.32mm to φ 0.65mm (AWG 28 – 22)
Twisted Wire : 0.08mm2 to 0.32mm2 (AWG 28 – 22), φ 0.12 mm or more in diameter
Stripping Length : 9 to 10 mm
Isolation CH1, CH2, CH3, CH4, USB, and Preheat are isolated. (Battery terminals are not isolated from the CH1-CH4 input terminals.)
CH1-CH4 Maximum Applied Voltage : ± 50 V
Electrical Isolation Resistance : 50 MΩ or more （DC ± 250 V）
Dimensions H 120 mm x W 75 mm x D 32 mm
Weight Approx. 190 g (including batteries)
Operating Environment Temperature: 0 to 50 °C
Humidity: 90 %RH or less (no condensation)
Accessories AA Alkaline Battery x 2, USB Communication Cable (US-15C), Software (CD-ROM), Card Slot Cover, User’s Manual Set (Warranty Included)
  • *1 : When “Auto” is selected, measurement range will be automatically changed according to the voltage being measured.
  • *2 : If the logging capacity is not filled at the end of one recording session, the logger can record up to 30 times.
  • *3 : A memory card can be used to transfer recroded data from a logger to a PC. However, measurement data cannot be directly recorded into a memory card.
  • *4 : Battery life varies depending upon the measurement interval and 50-60 Hz filter setting. All estimates are based on operations carried out with a new battery and are in no way a guarantee of actual battery life.

Dimensions

  • 1. Input Terminal
  • 2. Preheat Terminal
  • 3. Coupling Lug
  • 4. LCD Display
  • 5. Touch Panel (touchpad and control wheel)
  • 6. SD Memory Card Slot
  • 7. USB Port
  • 8. Battery Cover
