RN310

  • Long-Range Data Transmission
  • LoRaWAN Communication
  • Internal High Accurate Temp/RH Sensor
  • Built-In Batteries
  • Ultra-Low Power Consumption
  • Food-Safe Material
  • Radionode365 Cloud Supported

$145.00

Normal delivery 1-2 weeks

Description

RN310 Temperature/Humidity Data Logger via LoRaWAN

RN310 is a simple, compact, and powerful LoRaWAN® temperature & humidity sensor. It is equipped with high-precision sensors and a waterproof design, applicable for accurate temperature and humidity data detection in various harsh environments. FDA-approved food-grade material’s enclosure allows it to be placed in freezers and refrigerators and in contact with food or medicines safely. In addition to LoRaWAN® technology with low power consumption, it has built-in high-capacity batteries available for usage for up to 5 years. Moreover, RN310 is compatible with both Radioniode LoRaWAN® Gateway and IoT Cloud Radionode365 to achieve remote data monitoring and management.

Includes:

  • RN310 Temp/RH Wireless Transmitter
  • 2700 mAh Li-COCL2 Battery (2EA)
  • Wall Mounting Kit
  • Fixing Screw (2EA)

Applications:

  • Cold Storage for Bio, Food
  • Agricultural Greenhouses
  • Building Energy Usage Monitoring
  • Medicine and Medical Goods Storage Sites
  • Semiconductor Production Lines

Note: this device requires a LoRaWAN Gateway and the “RNtools” Android App for RN310 configuration

Specifications

Wireless Telecommunications LoRaWAN V1.0.3, OTAA/ABP Class A
CN470/IN865/RU864/EU868/US915/AU915/KR920/AS923
TX:20dBm / 16dBm / 19dBm
Sensitivity: -137 dBm @ 300 bps
Internal Temp/RH Sensor CH1: Temperature (-30°C ~ 60°C)
CH2: Humidity (0 ~ 100%RH)
Accuracy Temp. Accuracy: ±0.2°C
R.H. Accuracy: 2.0 %RH
Resolution Temp. Resolution: 0.1°C
R.H. Resolution: 0.5 %RH
Operating Condition -30 ~ 60°C / 5 ~ 95 %RH (Non condensing)
Operation Power On & Off: NFC Configuration via Mobile App, Power Button (Internal)
Configuration: NFC Configuration via Mobile App
Material ABS + PC (Food Grade)
Sensing Interval 1 ~ 1000 mins
Sending Interval 1 ~ 1000 mins
Battery / Life Span 2 x 2700 mAh Li-COCL2 Battery
5 Years @ 10 min interval
Protection IP65
Buzzer Min.80dB, at 4.0KHz, L 6.2mm x Φ 12.8mm
How To Setup NFC Configuration via Rntools (Android App)
Wall Mount Types Screw Hole (Standard) or Magnet (Optional Add-on)
Weight 115g

Software

Radionode365 is a sensor data monitoring web service for smart sensor management. Remotely integrated management with Radionode365 that satisfies both users and administrators.

Features:

  • Real-time integrated dashboard with numerous measurement points at a glance
  • Send text, phone, and email notifications
  • Simple and user-friendly device registration
  • Ability to set various alarm exceptions including power and network outage alarms
  • Open API and IQ/OQ validation support
  • User history management: separation of admin/user privileges, designation of a person in charge by management point

Downloads

User Guide (PDF file)
RNTools Android App (APK file)
