TandD TR-55i-TC

Measurement Range: -199 to 1700°C
Thermocouple Type K, J, T, S
Logging Capacity: Up to 16,000 Readings
Low energy consumption for long battery life
Downloading Data: Infrared Communication / Optical Communication
Warning Monitoring Function
Compact Waterproof Type
A 9.5% Tariff Surcharge will be added to this item at checkout

Download Specification Sheet

$219.00

Normal delivery 1-2 weeks

SKU: TR-55i-TC Categories: Battery Powered Data Loggers, Cooler Temperature Monitoring, Featured Food Temperature Monitoring Systems, Featured Freezer Temperature Monitoring Systems, Featured HVAC Application Products, Food Temperature Monitoring, Freezer Monitoring, HVAC Data Loggers, Refrigerator and Freezer Monitoring, TandD, Thermocouple Data Loggers, TR-5i Infrared Data Loggers, Transport Data Loggers

Description
Software

Description

With dimensions of 62 x 47 x 19mm (2.4 x 1.8 x 0.75in) TR-5i series loggers may be small, but they are built to last. In addition to the LCD on the front panel, the built-in alarm LED makes warnings easily visible. The TR-55i-TC is designed for highly versatile thermocouple sensors and measures a wide range of temperatures from -199℃ to 1760℃.

As it is possible to connect to the most commonly used thermocouple sensors in the industry for measuring middle to high-range temperatures, the TR-55i-TC is most suitable for temperature control management in facilities such as factories and plants. For customers who already have thermocouple sensors, all you need to do is connect and start recording!

By connecting TandD’s Communication Port TR-50U2 to your PC via a USB cable, you can easily download data by placing the logger face down on the port. Data downloaded to your PC can then be viewed and analyzed with our Windows-compatible software “T&D Graph.”

Software

The software included with the TR-5i series data loggers makes it possible to create detailed recording settings. Set the interval at which you want recording to occur and the timing at which you want the recording to start. When monitoring measurements for warnings the LED on the logger will flash and the time of the warning will be recorded.

Graphing software from TandD

The included graph application allows easy analysis of the recorded data. All data can be viewed in one graph window, regardless of the data format or from what type of device the data came from. Search and filter to get only the data you need. Data can be output as a text format file (CSV).
