tr-50u2 communication port

TandD TR-50U2

  • Comm Interfaces: USB, Optical
  • Power: USB Bus Power
  • Operating environment:
    • Temperature: -10 to 60°C
    • Humidity: less than 90%RH (No condensation)
    • Do not use it if the Data Logger is wet.
  • Dimensions: H:80mm × W:56mm × D:16.5mm
  • Accessories: USB Communication Cable, Software(CD-ROM), Manual
  • A 9.5% Tariff Surcharge will be added to this item at checkout

$189.00

Normal delivery 1-2 weeks

Get a QuoteGet More Info
SKU: TR-50U2 Categories: , , ,

Description

The TR-50U2 Communication Port is a communication cradle necessary for connecting TR-5i series loggers and a PC to carry out settings and download data. The communication port uses a simple USB connection. Place the logger face down on the port and use TandD’s Windows software “T&D Recorder for Windows” to carry out settings and download data. All you need to do is connect the communication port to your PC with a USB cable. Data can be downloaded in a snap! One unit of full data can be downloaded in just 25 seconds.

TR-50U2 Features:

  • Use for downloading data directly to a PC
  • Download data from a logger at full storage capacity in about 25 seconds.
  • The unit operates via USB bus power so no need for more wires and plugs.
  • Ability to specify a time period of data for downloading so you get only the data you want.

Compatible with TR-5i series:

TR-51i Temperature Data Logger
TR-52i Temperature Data Logger with External Sensor
TR-55i-TC Thermocouple Data Logger
TR-55i-Pt Temperature Data Logger
TR-55i-V Voltage Data Logger
TR-55i-mA 4-20mA Data Logger
TR-55i-P Pulse Data Logger
